70 mm Footwear Testing Equipment Safety Footwear insole board Flexing tester
Detailed Descriptions:
Used for testing the safety insole board folding resistance. Fixed clamping part of insole board in the middle, 70 mm from the clamping area(front of insole board) with two fixed rod clamp specimen, the fixed link can do reciprocating crooked moves around holding place.
Specifications:
Test group number: 2set
Bending frequency: 16±1 rps
The Bend largest vertical height:33 mm
Crooked distance: 70 mm
Counter: LCD display 0~99999999
Dimension: 710×360×360mm (L×W×H)
Weight: 85 kg approx.
Standard: EN12568,GB/T 20991
Parameters:
|
Flexing Frequency |
16±1 cycle/min |
|
Flexing Height |
33mm |
|
Flexing Space |
70mm |
|
Sampling |
2sets |
|
Counter |
LCD Display, 0-99,999,999 |
|
Main Unit Dimension |
71 x 36 x 36cm |
|
Control Box Dimension |
23 x 26 x 25cm |
|
Weight |
85kg |
|
Power |
1Φ, AC220V(Specified by user) |
